V Dock Fender High Impact Absorption Excellent Compression Resistance Long Service Life
Description
V Type Fender is a high-performance marine protection solution designed to absorb impact energy and protect vessels and port infrastructure during berthing operations. Manufactured from premium-grade marine rubber with excellent compression resistance and durability, it provides reliable shock absorption and long-term operational stability. The V-shaped profile enhances energy distribution, reducing docking stress and minimizing structural damage to both ships and harbor facilities.
Case Study
A medium-sized commercial port handling container vessels up to 20,000 DWT experienced frequent docking damage and high maintenance costs due to inadequate fender systems. After installing V Type Fender units along the berthing line, impact forces during vessel contact were significantly reduced, resulting in fewer structural repairs and improved operational safety. The port reported a 35% decrease in docking-related maintenance expenses within the first year and enhanced berthing efficiency. Feedback from port operators highlighted the product’s superior energy absorption and long service life as key contributors to operational improvements.
Specifications
| Product Name |
V Type Fender |
| Material |
High Performance Natural Rubber |
| Standard |
HGT2866-2016, PIANC2002 |
| Shape |
V Type |
| Feature |
Easy Replacement Firm for Installation |
| Part |
Dock Bumper |
| Usage |
Dock Port Wharf Boat Ship |
| Surface |
Matte/Smooth |
| Packing |
Pallet or Wooden Case |
| Keywords |
Arch Rubber Fender/V Rubber Fender |
| Model |
A |
D |
E |
F |
H |
K |
M |
R x Q |
Lmax |
| V Type |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
| HM-VTF150 |
50 |
240 |
326 |
98 |
150 |
16 - 20 |
108 |
20 × 40 |
3000 |
| HM-VTF200 |
50 |
320 |
422 |
130 |
200 |
18 - 25 |
142 |
25 × 50 |
3000 |
| HM-VTF250 |
62.5 |
400 |
500 |
163 |
250 |
20 - 30 |
164 |
28 × 56 |
3500 |
| HM-VTF300 |
75 |
480 |
595 |
195 |
300 |
25 - 32 |
194 |
28 × 56 |
3500 |
| HM-VTF400 |
100 |
640 |
808 |
260 |
400 |
25 - 32 |
266 |
35 × 70 |
3500 |
| HM-VTF500 |
125 |
800 |
981 |
325 |
500 |
25 - 32 |
318 |
42 × 84 |
3500 |
| HM-VTF600 |
150 |
960 |
1160 |
390 |
600 |
28 - 40 |
373 |
48 × 96 |
3000 |
| HM-VTF800 |
200 |
1300 |
1550 |
520 |
800 |
41 - 50 |
499 |
54 × 108 |
3000 |
| HM-VTF1000 |
250 |
1550 |
1850 |
650 |
1000 |
50 - 62 |
580 |
54 × 108 |
3000 |
| *Note: Other sizes can be customized according to the requirements. |
Features
Superior Impact Absorption
V Type Fender is engineered for high energy dissipation, effectively reducing docking forces and protecting both vessels and port structures. Its optimized V-shaped design distributes impact loads evenly, minimizing localized stress and structural wear.
Durable Marine-Grade Construction
Manufactured from high-quality rubber materials, the fender offers excellent resistance to seawater corrosion, UV exposure, and mechanical degradation. This ensures long-term performance in harsh marine environments with minimal maintenance requirements.
High Compression and Elastic Recovery
The product maintains structural integrity under repeated compression cycles, providing reliable performance over extended operational periods. Its strong rebound capability helps restore shape and functionality after impact.
Low Maintenance and Cost Efficiency
Designed for durability and ease of use, V Type Fender reduces maintenance requirements and operational costs. Its robust construction extends service life, offering a cost-effective solution for marine infrastructure protection.
Applications
Port and Harbor Berthing Protection
V Type Fender is widely used in commercial ports and harbors to safeguard docking areas from vessel impact. It enhances operational safety and reduces structural damage, supporting efficient maritime logistics.
Shipyards and Dry Dock Facilities
In ship maintenance and repair environments, the fender provides reliable protection during vessel movement and handling operations. Its shock-absorbing properties minimize structural stress and enhance workplace safety.
Offshore and Marine Engineering Projects
The product supports offshore operations by providing impact protection and structural stability in marine engineering applications. Its durability and performance make it suitable for demanding maritime environments.
Why Choose Hongruntong Marine
Industry Expertise and Engineering Excellence
With extensive experience in marine protection solutions, we deliver high-quality fender systems designed for reliability and performance. Our engineering capabilities ensure products meet international standards and operational requirements.
Premium Materials and Advanced Manufacturing
We utilize marine-grade rubber and precision manufacturing techniques to produce durable and efficient fender systems. This
commitment to quality enhances product longevity and operational effectiveness.
Customized Solutions for Diverse Applications
Understanding that every port and vessel operation is unique, we offer tailored fender designs to meet specific project requirements. Customized solutions optimize performance and compatibility with existing infrastructure.
Comprehensive Customer Support
From product selection to installation guidance and after-sales service, we provide end-to-end support to ensure customer satisfaction. Our professional team is dedicated to delivering reliable solutions and long-term value.
FAQ
1. What materials are used in V Type Fender?
V Type Fender is manufactured from high-quality marine rubber with excellent compression resistance and durability. These materials ensure reliable performance in harsh marine environments and long service life.
2. Can the fender be customized for different port requirements?
Yes, we offer customized solutions to meet specific operational needs. Dimensions, load capacity, and installation configurations can be tailored to suit diverse marine applications.
3. How does V Type Fender reduce docking damage?
The V-shaped design absorbs and distributes impact energy, minimizing direct force on vessels and port structures. This reduces structural stress and enhances operational safety.
4. What maintenance is required?
V Type Fender requires minimal maintenance due to its durable construction. Periodic inspections and cleaning are recommended to ensure optimal performance and longevity.
5. Is the product suitable for extreme weather conditions?
Yes, the fender is designed to withstand UV exposure, seawater corrosion, and temperature variations. Its robust materials ensure reliable performance in diverse marine environments.
